Jindal MLC Pipes deliver unmatched flexibility and strength for hot and cold water supply. Built with multilayer composite technology, they combine aluminum strength with plastic flexibility. The result is easy bending, fewer fittings, and long-lasting joints. Tested to Indian & international standards, these pipes deliver 50 years of consistent, maintenance-free service.
PE-AL-PE / PERT-AL-PERT
Inner and Outer layers of HDPE (High Density Polyethylene) and Middle layer of Aluminium.
- SIZEIDODCOIL16mm12mm16mm200mtr20mm16mm20mm200mtr25mm20mm25mm100mtr32mm25mm32mm100mtr40mm32mm40mm100mtr50mm40mm50mm50mtr63mm50mm63mm6mtr75mm63mm75mm6mtr
Hot & Cold Water supply
Hot & Cold Water, Drinking Water, Solar Water​, HVAC systems, Underfloor Heating & Cooling
Pressure Rating
13.8 bar at 23°C
11.0 bar at 60°C
6.9 bar at 82°C
Temperature Rating
-20°C to 82°C
Certification
IS : 15450 (2022)
ISO 21003
ASTM F 1282
Pressure Rating
13.8 bar at 23°C
11.0 bar at 60°C
6.9 bar at 82°C
Temperature Rating
-20°C to 82°C
Certification
IS : 15450 (2022)
ISO 21003
ASTM F 1282
MLC Pipe: Quality Assured
Jindal MLC pipes are premium piping solutions designed for both hot and cold water applications. Built with a 5-layer PERT-AL-PERT structure, they offer flexibility, corrosion resistance, and long-term durability across multiple applications.
PE-AL-PE / PERT-AL-PERT
Multi-layer composite structure with Inner and Outer layers of HDPE (High Density Polyethylene) and Middle layer of Aluminium.
- SIZEIDODCOIL16mm12mm16mm200mtr20mm16mm20mm200mtr25mm20mm25mm100mtr32mm25mm32mm100mtr40mm32mm40mm100mtr50mm40mm50mm50mtr63mm50mm63mm6mtr75mm63mm75mm6mtr
Hot & Cold Water supply
Hot & Cold Water, Drinking Water, Solar Water​, HVAC systems, Underfloor Heating & Cooling
Pressure Rating
13.8 bar at 23°C
11.0 bar at 60°C
6.9 bar at 82°C
Temperature Rating
MLC PIPES: -20°C to 82°C
MLC PRO: -20°C to 95°C
Certification
IS : 15450 (2022)
ASTM F 1282
PRODUCT FEATURES
Multi-Layer tech
Combines polymer and aluminum layers for strength, durability, and reliability.
Bendable
Easily bends around corners, reducing fittings and speeding up installation.
Food Grade Materials
Manufactured with food-grade materials for pure, hygienic water supply.
Higher Flow Rates
30% Better flow rate compared to traditional piping systems
50 Years working life
Rust & Corrosion free, engineered to last over five decades.
PRODUCT RANGE
FITTING TECHNOLOGIES
MLC pipes are compatible with multiple fitting technologies, providing flexibility across residential, commercial, and industrial installations.
Installation Guide
1. Cut the pipe from a perpendicular angle using the Pipe Cutter
2. Round and chamfer the pipe using a reamer with 3–5 rotations for proper insertion
3. Use the Internal/External Bending Springs for bending the pipe to avoid dents
4. Disassemble the fittings and put the Nut & Split ring over the pipe
5. Insert the fitting nozzle into the Pipe opening
6. Tighten the nut, and you're ready to go!
Learn the proper way to install Jindal Multi Layer Composite Pipes by watching a quick video linked below. When installed correctly there is zero chance of leakages and you will have a piping system that will last you over 50 years.
​Engineering Behind Jindal MLC Pipe
Jindal MLC pipe is built on an advanced 5-layer PERT-AL-PERT composite structure, combining aluminium strength with polymer flexibility for modern plumbing systems.
The aluminium core provides structural stability, pressure resistance, and dimensional control, while the inner and outer polymer layers ensure corrosion-free performance and smooth water flow. Strong adhesive bonding layers hold the structure together for long-term reliability.
Key engineering features:
-
5-layer PE-AL-PE / PERT-AL-PERT structure
-
Aluminium core for strength and stability
-
Polymer layers for corrosion resistance and smooth flow
-
Adhesive bonding for structural integrity
-
Designed for long-term pressure and thermal performance
This makes MLC pipe suitable for demanding residential, commercial, and infrastructure applications.
​Hot & Cold Water Performance
MLC pipe systems are designed for consistent performance in both hot and cold water applications.
Unlike conventional pipes, they offer low thermal expansion, which reduces stress on joints and improves long-term system stability.
Performance advantages:
-
Suitable for continuous hot and cold water flow
-
Low thermal expansion reduces pipe stress
-
Stable under pressure fluctuations
-
Works in concealed and exposed installations
-
Maintains efficient flow in long pipelines
This makes them ideal for modern residential, high-rise, and institutional plumbing systems.
​Built for Long-Term Plumbing Performance
Builders, consultants, and plumbing professionals prefer composite pipes in India for their balance of performance, reliability, durability, and installation efficiency. Their advanced construction offers several advantages over conventional piping systems:
-
Lower thermal expansion
-
Corrosion and scaling resistance
-
Smooth, consistent water flow
-
Flexible and easy installation
-
Long service life
-
Suitable for hot and cold water applications
For projects that demand long-term performance and value, a quality composite pipe system is a dependable choice.
​Key Advantages of MLC Pipe
MLC pipes are best suited for environments where durability, safety, and installation efficiency are critical. They perform especially well in systems where traditional piping faces issues like corrosion, leakage, or thermal stress.
Ideal applications:
-
High-rise residential buildings
-
Commercial complexes and office infrastructure
-
Hotels, hospitals, and healthcare facilities
-
Hot water distribution systems
-
Concealed modern plumbing networks
Explore real-world applications on our Projects Page to understand how Jindal MLC pipes perform in real residential, commercial, and infrastructure projects.
-
Get Jindal MLC Pipe Price
The exact Jindal MLC pipe price depends on factors such as pipe size, specifications, length, and project requirements. With a nationwide network of more than 100 channel partners, we ensure reliable availability and support for projects of every scale.
For bulk requirements, we also offer project-based pricing solutions. Contact our team to learn more about Jindal MLC pipe pricing or click the button below to request a quotation.
COMPARISON
JINDAL vs OTHER PIPES
.png)
Corrosion resistance
Never rusts
No rust, but may turn brittle
Scale Build-up
Zero scaling
Minor scaling over time
Weight
Lightweight
Lightweight
Flexibility
Bendable, No elbow needed
Rigid, elbows needed
Pressure Resistance
Upto 15 Bar
10-12 Bar
Thermal Expansion
Very Low
Moderate
Installation Ease
Quick with compression/crimp fittings
Medium, needs solvent cement
Leak Resistance
Leak Proof system with minimal joints
More Joints, vulnerable to leakages
Working life
50+ Years
35-40 Years
Water safety
Food Grade material
Made from toxic chemicals
Overall Cost
5-7% more expensive than CPVC
Slightly cheaper than MLC
Corrosion resistance
Never rusts
Prone to rust and corrosion
Scale Build-up
Zero scaling
High, which reduces flow
Weight
Lightweight
Heavy, difficult to handle
Flexibility
Bendable, No elbow needed
Rigid, elbows needed
Pressure Resistance
Upto 15 Bar
Upto 15 Bar, but joint leakage possible
Thermal Expansion
Very Low
Low, but deforms with age
Installation Ease
Quick with compression/crimp fittings
Difficult, requires threading and welding
Leak Resistance
Leak Proof system with minimal joints
Joint leakage common, especially at threads
Working life
50+ Years
10-15 Years due to corrosion
Water safety
Food Grade material
Can contaminate water with rust
Overall Cost
Similar initial cost, but zero maintenance
Much higher long term cost
Corrosion resistance
Never rusts
Excellent Corrosion resistance
Scale Build-up
Zero scaling
Minimal scaling
Weight
Lightweight
Heavy, difficult to handle
Flexibility
Bendable, No elbow needed
Rigid, elbows needed
Pressure Resistance
Upto 15 Bar
Vert high pressure resistance
Thermal Expansion
Very Low
Very low
Installation Ease
Quick with compression/crimp fittings
Difficult, requires threading and welding
Leak Resistance
Leak Proof system with minimal joints
Reliable joints but welding quality critical
Working life
50+ Years
50+ Years
Water safety
Food Grade material
Hygienic Non Toxic
Overall Cost
Much cheaper
Very High
Corrosion resistance
Never rusts
Corrosion-resistant but can be affected by some chemicals
Scale Build-up
Zero scaling
Minimal scaling
Weight
Lightweight
Lightweight
Flexibility
Bendable, No elbow needed
Rigid, elbows needed
Pressure Resistance
Upto 15 Bar
Upto 10 Bar
Thermal Expansion
Very Low
Medium
Installation Ease
Quick with compression/crimp fittings
Fusion welding required
Leak Resistance
Leak Proof system with minimal joints
Reliable joints but welding quality critical
Working life
50+ Years
25-50 Years
Water safety
Food Grade material
Hygienic Non Toxic
Overall Cost
Cost effective over lifetime
Lower Initial cost
Comparison Factor | JINDAL MLC | CPVC | GI | SS | PPR |
|---|---|---|---|---|---|
Corrossion resistance | Never Rusts | No rust but may turn brittle | Poor, rusts over time | Excellent | Excellent |
Scale build-up | None | Minimal | Heavy over years | Some possible | Minimal |
Weight | Lightweight | Lightweight | Heavy | Heavy | Lightweight |
Flexibility | Bendable, no elbow needed | Rigid, elbow needed | Rigid, elbow needed | Rigid, elbow needed | Rigid, elbow needed |
Pressure resistance | Upto 15 Bar | 10-12 Bar | Upto 15 Bar, but joint leakage possible | Very High | 10-12 Bar |
Thermal expansion | Very Low | Moderate | None | None | High |
Installation | Quick with Compression/Crimp fittings | Moderate (glue required) | Difficult (Threading) | Difficult (Welding) | Difficult (Fusion welding) |
Leak resistance | Leak proof system with minimal joints | More joints, vulnerable to leakages | Joint leakage common | Reliable joints, but welding quality critical | Reliable joints, but welding quality critical |
Working life | 50+ Years | 30-40 years | 10-15 Years | 50+ Years | 25-50 Years |
Water safety | Food Grade material | Made from toxic chemicals | Can contaminate water with rust | Hygienic non toxic | Hygienic non toxic |
Cost (Overall) | Low-Med | Low-Med | Medium | Very High | Low-Med |
When installed correctly there is zero chance of leakages and you will have a piping system that will last you over 50 years.
Learn the proper way to install Jindal Multi Layer Composite Pipes by watching a quick video linked below.
